Superfine Mill

Superfine Mill

The superfine mill can grind barite, calcite, feldspar, talc, marble, limestone, dolomite, fluorite, bentonite, kaolin, gypsum from ≤35 mm into 0.015 mm. Both Electric engine and Diesel engine are optional. Capacity:from 1.3 t/h to 35 t/h flexible.

Advantages

Superfine mill is a kind of grinding equipment belonging to micro powder mill. Because its finished product is finer than micro powder mill, so, it's also called superfine micro powder mill. Superfine mill is developed to solve insufficient fineness when grinding materials, which more saves energy and reduces cost compared with traditional jet mill.

Ultrafine grinding mill is widely used in non-metallic mineral industry, which has such features as stable performance, wide range of application, simple structure, convenient operation, large processing capacity, energy conservation and environmental protection. It's high-tech grinding equipment.

Superfine micro powder mill is a kind of ultrafine powder processing equipment with high efficiency and low emission reduction researched and designed by our company, which successfully solves problems of low efficient and high cost of je mill when manufacturing ultrafine powder. It has confirmed by more than thousand users that the superfine mill has superior product performance, stable quality and significant economic benefits, thus greatly improving product grades and additional value.

You can contact us directly to get the quotation of superfine mill of leave a message for consultation. We will rely you as soon as possible.

Model Specifications

Type HGM100 HGM120 HGM130 HGM160 HGM175
Feeding
size (mm)
<20 <20 <25 <30 <35
Size of finished
product (mm)
0.25-0.015 0.25-0.015 0.25-0.015 0.25-0.015 0.25-0.015
Shift output
of different
material
fineness (t/h)
0.8-6 1.2-8 1.8-12 2.8-20 3.5-25
Rotate speed of
central shaft (r/min)
140 140 105 82 75
Diameter of
pulverizing ring (mm)
1075×200 1280×240 1400×240 1770×280 1900×300
Diameter of pulverizing
roller (mm)
320×200 370×240 410×240 450×280 500×300
Main
Motor (kw)
37 55 75 132 160
Fan
Motor (kw)
45 55 75 132 160
Analyzer
motor (kw)
11 15 18.5 22 30
