Single-Stage Crusher

Single-Stage Crusher

The single-stage crusher can crush bricks,gypsum, limestone, coal, slag etc. from ≤800 mm to ≤1250 mm. Both Electric engine and Diesel engine are optional. Capacity : from 100t/h to 420 t/h flexible.

Advantages

Single-stage crusher is a new type of mining stone crushing equipment developed on the basis of impact hammer crusher, which is of high yield and reliability. Single-stage crusher can crush ores to below an average of 5 mm at a time. The crushed materials have uniform particles.



Besides, single-stage crusher can also reduce the number of stone crushing and generation of stone powder, which simplifies production process and save production cost. So, single-stage crusher is ideal updated product of two-stage and three-stage crushing machines.

Single-Stage Crusher

When crushing materials, high-speed running hammer head will continuously crush bulk materials which enter crushing cavity through feeder; the crushed materials will be discharged from the grate plate, materials that cannot be discharged will remain in the crushing cavity until they are crushed to required size, thus being discharged for grate plate.

Single-stage crusher is mainly used to crush brittle materials with medium hardness, such as limestone, gypsum, coal, ceramic and clay mixture. Single-stage hammer crusher as large mining crushing equipment is relatively economy and reliable.

Model Specifications

Model Type Rotor diameter Feeding size
(mm)
Product Size
(mm)
Capacity
(t/h)
Power
(kw)

DPC140

Single Rotor

1400

≤800

<3-8

100-140

160-220

DPC160

1600

≤1000

150-240

280-355

DPC200

2000

≤1250

330-420

500-630
