Heavy Hammer Crusher

Heavy Hammer Crusher

Heavy hammer crusher can crush all types of ore with compressive strength less than 100MPa and moisture content not higher than 15% from 1700 mm into 25 mm.


Heavy hammer crusher is a kind of new crushing machine integrating advantages of jaw crusher, impact crusher and hammer crusher, which can directly crush chunks of stones and automatically feed. It is advanced stone crushing equipment with fully automatic line production.

Heavy Hammer Crusher

Heavy hammer rock crusher has obvious advantages in crushing materials with medium or over medium hardness, which has strong cost performance in crushing granularity and energy consumption compared with impact crusher.

Heavy Hammer Rock Crusher

Working Principle of Heavy Hammer Rock  Crusher

Driven by motor, the rotor drives hammerhead to do high-speed circular motion; when materials enter crushing cavity, large materials are stacked in the special central single strip inside the machine, crushed materials with too large granularity and new materials are impacted by impact plate for again crushing, thus making coarse and medium crushing at one step. Finally, the materials that meet the requirements will be discharged.

Fote Machinery is a professional heavy hammer crusher supplier and manufacture, our heavy hammer crusher price is very reasonable. Customers are welcomed to get in touch with us!

Model Rotor diameter×length
Feed opening Length×width
Feeding size
Total weight
PCZ1308 1300×1000 930×650 ≤600 100-180 4P   132 2818×2100×2391
PCZ1410 1400×1000 1020×750 ≤700 180-230 4P   160/90×2 2830×2100×2485
PCZ1610 1600×1000 1150×1000 ≤900 260-350 4P   220-250/132×2 3370×2415×2751
PCZ1615 1600×1500 1400×1000 ≤900 380-550 4P   355-400/200×2 3371×2925×2752
PCZ1716 1700×1600 1640×1300 ≤1200 600-1100 4P   250×2 3520×3000×3210
PCZ1720 1700×2000 1980×1300 ≤1200 800-1200 4P   400×2 3670×3390×3328
PCZ1920 1900×2000 1850×1600 ≤1500 900-1500 2×500 3729×3300×4451
PCZ2225 2200×2500 2100×2300 ≤1700 2000-2600 1250 3931×4100×4660
